Product Introduction
Fishcor Plate Heat Exchanger stainless steel Frame Gasketed Heat Exchanger For water heating,PHE Producer
Brand：Fisil (fishor) Item：Plate heat exchanger
1.Frame material 3 kinds: commonly carbon steel paint ,carbon inner with stain steel out surface,Pure stain steel frame
2.Port 4 kinds : stud bolts with lining,selding neck flange,lapped flange,lapped flange with plain collar.
3.Plate material & thickness : Commonly AISI304/316/Ti plate 0.5/0.6mm
4.Gasket material : EPDM&NBR&FPM or others.(Most commly use is EPDM)
5.Plate models:Various
6.we offer perfect after-sale service system for repair and training.
7.We offer professional technology selection service,free service to help choose Appropriate models for you.
8.Our products are mainly to many countries,such as Pakisitan,India,Malaysia,Russia,Austrilia,Vietnam,Spain and so on.
9.Packing size: standard export wooden packing or steel frame packing.
10.Weight and packing size:we offer specized Chinese and English calculation books.
10.Our MOQ:1pcs Nearby Port:Shanghai we do EXW,FOB,CIF
11.100% in advance before shipment.payment terms : TT/L/C
Product Features:
1.High heat transfer cefficient
2.Heat transfer temperature difference is small
3.Save a space
4.Not easy to scale
5.Load incerease and decrease is convenient
6.So the heat exchange process combination
7.Easy operation and maintenance.
Pressure vessel code technical standard
- American ASME stanards
- The 3A standard
- The ISO 9001 quality system certification
- German DIN standard
- CCS china classification society certification.
Product Specification：
FISHOR PHE Technology Specification
Model
DN
Flow Rate Max
P.NO
MAX
Max surface
mm
㎡
pcs
㎡
FS40
32
20
50
3
FS70
50
40
76
5
FS140
50
40
427
59
FS170
50/65
40
609
100
FS190
65
65
609
115
FS220A
100
180
698
146
FS220B
100
165
538
118
FS420A
150
380
670
274
FS420B
150
360
532
223
FS620
150
380
670
415
FS430
200
700
695
300
FS650
200
700
695
450
FS1000
200
700
695
695
FS1300
200
700
695
900
FS800A
300
1600
930
744
FS800B
300
1600
930
750
FS1200
300
1600
930
1115
FS1900
300/500
1600
930/930
1750/2210
FS2500
300
1600
930
2334
FS3000
500
4000+
930
1860
Fisil (fishor) is a professional supplier of plate heat exchangers, which combines the design, manufacture, consultation and after-sale service of plate heat exchanger products. The company introduced the technology and technology of Austria Fisher plate heat exchanger in 2008 to become our company's partner in China.
Fisil (fishor) has a professional team that has accumulated decades of experience in the field of heat exchange. It is committed to the design, manufacturing and maintenance services of heat exchange equipment, as well as technical innovation.
At the same time, our company has the right of independent import and export, and has a wide range of partners and procurement channels at home and abroad. Both domestic and foreign can purchase the whole machine and core components of international famous brand heat exchangers. It can provide the domestic partners with the above products, which can effectively reduce the cost of purchasing, and provide satisfactory technical consultation and technology. Therefore, Austria FISCHOR (Fisil) plate heat exchanger brand provides you with the most advanced and optimal product in the world. It is also the best choice for you.
